CE Certified Jp Jianping Large Auto Spare Parts Engine Crankshaft Dynamic Balancing Machines

CE Certified Jp Jianping Large Auto Spare Parts Engine Crankshaft Dynamic Balancing Machines

Crankshaft Balancing Machine, Balancing Machine, Dynamic Balancing Machine manufacturer / supplier in China, offering CE Certified Jp Jianping Large Auto Spare Parts Engine Crankshaft Dynamic Balancing Machine, Jp Jianping Turboprop Turbojet Aircraft Turbine Balancing Machinery, Jp Jianping Motorcycle Brakes Automotive Brakes Balance Machine and so on.

Product Details

CE Certified Jp Jianping Large Auto Spare Parts Engine Crankshaft Dynamic Balancing Machines




CrankshaftBasic Info

  • Model NO.: PHQ-500H

  • Weight: 500-1000Kg

  • Length: 1780 Mm

  • Height: 1300 Mm

  • Number of Package: 2 Pieces

  • Brand Name: Jp

  • Language: English,Russina,Chinese

  • Specification: ISO. CE. SGS

  • HS Code: 90311000

  • Type: Strength Testing Machine

  • Power Source: AC380V

  • Width: 700 Mm

  • Gross Weight: 550 Kg

  • Colour: Jp Standard or Custom

  • Place of Origin: Shanghai, China

  • Trademark: JP

  • Origin: Shanghai China

Product Description



CE Certified Jp Jianping Large Auto Spare Parts Engine Crankshaft Dynamic Balancing Machines


Production Description:
1) Specially designed brackets transmit mechanical force with low vibration damping
2) Durable and reliable sensor possesses good linearity
3) Permanent calibration brings high accuracy with a permission of large initial unbalance amount
4) Belt-driving offers higher precision and easier operation
5) Advanced electrical measuring system and friendly man-machine interface
6) Modular design offers a wide range of application

Range of Application:
This balancing machine is widely used in balancing rotatable bodies, such as kinds of medium-sized and small-sized motors rotors, impeller, fans, crankshaft, turbocharger, water pump, roller, grinding wheel, main shaft of machine tool, textile machinery, tool, spindle, etc...Driven by belt, equipped with Variable speed motor to drive. Which ensures high quality balancing and precision. Quick booting, easy operation. And high efficiency

Special Features:
The measuring unit employs JP-580 Electrical Measuring unit is a system of top function and precision. It can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer made in Yanxiang Industry Co, which equiped with 17-inch LCD screen and Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments
Factory Outlook:

Production Parameters:

Technical data at a glancePHQ-160HPHQ-300H PHQ-500H
Max Mass of Workpiece (kg)160300500
Max Diameter of Workpiece (mm)100012001500
Distance between Two Support Bearings (mm)150~1200160~1500  160~1500
Journal Diameter Scope of Workpiece (mm)10~140 20~180 20~180
Diameter Scope of Driving Belt (mm)30~35040~400 40~400
Rotation Speed when the Diameter of Driving Belt is 100mm (r/min) 756,1176 +Stepless speed regulation756,1176 +Stepless speed regulation840,1274 +Stepless speed regulation
Motor Power (kw)
1.5  (Frequency conversion)

1.5 (Frequency conversion)

2.2 (Frequency conversion)
Min Achievable Residual Unbalance Amount(emar)0.5g. mm/kg0.5g. mm/kg0.5g. mm/kg


After Sale Service:
Professional engineer and application specialists respond to your requests efficiently
Online via SKYPE MSN; Also through mail, voice phone message and fax if network is not accessible for customer
Follow up the case, record the entire process. Solution will be provide with 24 hours
Meanwhile, the problem complaint will be reported to QC department
QC will find defect from which department, who is in charge to identify responsibility
Collecting and record customer respond, suggestion, requirement

Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.

About Us:

Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd. Is a professional manufacturer of dynamic balancing machine, which is high-tech technology enterprises of Optical-electro-mechanical Integration,

There are ten series and more than 40 models of balancing machines, including belt drive balancing machine, universal joint drive balancing machine, vertical balancing machine, cross flow fan blade balancing machine, drive shaft balancing machine, self-drive balancing machine and auto-positioning balancing machine, two-plane axial flow balancing machine, smart balancer, automatic balancing machine, soft bearing balancing machine, manual milling machine etc.
