Motor Rotor Balancing Machine With End Face Drilling Correction

1.Specially designed for medium and small motor rotor,impeller,roller,shaft etc 2.Belt-driving offers higher precision and easier operation 3.Counterweight removing device with pneumatic hold workpiece function, it can remove weight from machine directly, no need disassembly workpiece, this improves Work efficiency greatly.

Product Details

1.Specially designed for medium and small motor rotor,impeller,roller,shaft etc
2.Belt-driving offers higher precision and easier operation
3.Counterweight removing device with pneumatic hold workpiece function, it can remove weight from machine directly, no need disassembly workpiece, this improves Work efficiency greatly.


Technical data at a glancePHQ-Z160H
Max Mass of Workpiece(kg)160
Max Diameter of Workpiece (mm)Φ100-Φ300
Distance Between Two Support Bearings (mm)200~650
Journal Diameter Scope of Workpiece (mm)Φ 15~75 Can add to 75-180
Diameter Scope of Driving Belt (mm)Φmax300
Rotational Speed when the Diameter of Driving Belt is 100mm (r/min) 756,1176 Stepless speed regulation
Motor Power (kw)1.5 Frequency conversion
Length of Bed (mm)1500
Min Achievable Residual Unbalance Amount (emar)≤0.5g· mm/kg




Technical data at a glancePHQ-Z160H
Max Mass of Workpiece(kg)160
Max Diameter of Workpiece (mm)Φ100-Φ300
Distance Between Two Support Bearings (mm)200~650
Journal Diameter Scope of Workpiece (mm)Φ 15~75 Can add to 75-180
Diameter Scope of Driving Belt (mm)Φmax300
Rotational Speed when the Diameter of Driving Belt is 100mm (r/min) 756,1176 Stepless speed regulation
Motor Power (kw)1.5 Frequency conversion
Length of Bed (mm)1500
Min Achievable Residual Unbalance Amount (emar)≤0.5g· mm/kg
