Dual-Plane Vertical Balancing Machines

Dual-Plane Vertical Balancing Machines

1.Specially designed,solid brackets can effectively transmit mechanical force2.Durable and reliable sensor possesses high sensitivity and good linearity3.Permanent calibration brings high accuracy4.Sp

Product Details

Dual-Plane Vertical Balancing Machines


1.Specially designed,solid brackets can effectively transmit mechanical force

2.Durable and reliable sensor possesses high sensitivity and good linearity

3.Permanent calibration brings high accuracy

4.Special clamp offers higher accuracy and easier operation

5.Advanced electrical measuring system and friendly man-machine interface

6.As the customer's request,the de-weighting system can be equiped





Technical data at a glancePHLS-35QPHLS-100QPHLS-200Q
Max Mass of Workpiece (kg) 35 100 200
Max Diameter of Workpiece (mm) Φ800 Φ600 Φ600
Height of workpiece(mm) 200 300 300
Spindle speed(r/min) ~500 ~500 ~500
Motor power(kw) 1.53) 33) 33)
Min Achievable Residual Unbalance Amount (emar) 4g · mm/kg 4g · mm/kg 4g · mm/kg

1) With hood
2) Without hood

3) Frequency conversion
