Automatic Drilling Balancing Machines



Automatic Drilling Balancing Machines







 Production Description



• Manual loading and unloading

• 15-inch touch screen

• Advanced balancing measuring software

• Automatic measure,automatic milling and correction,automatic retest

• Rigidity structure design,with a longer use life



Range of Application



Automatc Vertical Balancing Correction Machine A1LZ1 is designed specially for the automatic balancing of  disc-shaped parts in one plane,

Automatc Vertical Balancing Correction Machine A1LZ1 with one station is one of  the advanced vertical balancing machine of shanghai jianping,the whole balancing task is competely automatically including measuring,indexing,milling correction and checking,A1LZ1 is a good choice to mass produce with short cycle time,high efficiency and high accuracy

Single-Station Auto-Drilling Balancing Machine

Parameters of Balancing Unit
Mass of Workpiece(kg)	35(clamp included)
Max Height of Workpiece (mm)	200
Max Diameter of Workpiece (mm)	400
Balancing Speed（r/min)	800
Motor Power（kw）	1.5
Min Achievable Residual Unbalance Amount (g.mm/kg)	3
Drilling Unit
Drilling Speed（r/min）	1500 frequency conversion
Cutting Spindle Motor Power(kw)	0.75
Max Allowed Correct Times	2
Machine Parameter
Machine Motor Power(kw)	7
Machine Weight(ton)	1.5
Dimensions(mm)	950*1700*2000
Pressure(Mpa)	0.4-0.8
Processing Period(s/pcs)	25-35
